80kVA Oil-Immersed Transformer

The S22-M-80 is an advanced oil-immersed transformer with a rated capacity of 80kVA, specifically designed to provide efficient and reliable power distribution in various applications. Part of the S22 series, this model represents the latest in high-efficiency transformer technology, offering excellent energy-saving performance while meeting the most stringent energy efficiency standards. The S22-M-80 is a robust solution for power distribution needs in a wide range of industries and settings.

Main Features:

High Efficiency and Energy Saving: This transformer integrates new materials and an optimized design, ensuring compliance with the latest energy efficiency standards. The result is a significant reduction in both no-load and load losses, which translates to lower energy consumption and reduced operational costs. By maximizing energy efficiency, the S22-M-80 helps businesses and organizations save on long-term power expenses while contributing to environmental sustainability.

Environmental Protection and Safety: The S22-M-80 is equipped with high-quality insulating oil, providing exceptional insulation performance and efficient heat dissipation to maintain optimal operating conditions. The oil also ensures that the transformer operates safely by preventing overheating. Moreover, the transformer includes an explosion-proof device, further enhancing its safety profile and making it suitable for use in hazardous or high-risk environments. These features work together to ensure that the transformer operates securely, even in challenging conditions.

Safety and Stability: This transformer boasts excellent overload capacity and strong short-circuit resistance, which ensures stable operation over the long term. These safety features are essential for protecting both the transformer and connected equipment from electrical faults or surges, offering peace of mind to users. With these safeguards, the S22-M-80 provides a reliable power supply for various applications, minimizing downtime and preventing equipment damage.

Low Noise: The S22-M-80 is designed with an optimized core and winding structure that significantly reduces noise levels during operation. This makes it particularly suitable for environments where noise control is important, such as residential areas, schools, and hospitals. The quiet operation of the transformer helps maintain a comfortable and undisturbed environment, making it a practical choice for urban or noise-sensitive locations.

Easy Installation: The S22-M-80 is designed for easy transportation and installation. Its moderate size and lightweight construction allow for quick and straightforward setup, reducing labor costs and installation time. Whether it's being installed in a new site or replacing an existing transformer, the S22-M-80 is easy to handle, making it a cost-effective solution for various projects.

Technical Parameters (Example):

Rated Capacity: 80kVA

Voltage Levels: Typically 10kV/0.4kV or other customer-specific configurations

Cooling Method: Oil-immersed self-cooling

Connection Group: Yyn0 or Dyn11

Insulation Class: Class B or higher

Protection Class: IP20 or higher

Application Scenarios:
The S22-M-80 transformer is highly versatile and can be used in a variety of sectors, including:

Small and Medium Industrial Fields: The S22-M-80 is ideal for small and medium-sized factories, workshops, and industrial facilities that require a reliable and efficient power supply. It supports operations across diverse sectors, from light manufacturing to assembly, ensuring that production lines and machinery function smoothly and without interruption.

Commercial Fields: This transformer is also perfect for commercial establishments such as shopping malls, office buildings, hotels, and retail outlets, providing a dependable power source to support daily business operations. Whether powering lighting, HVAC systems, or other commercial infrastructure, the S22-M-80 ensures that businesses can operate without power disruptions.

Civil Fields: For residential areas, schools, hospitals, and other public buildings, the S22-M-80 offers a stable and reliable power supply. Its efficient performance ensures that essential services are maintained, with minimal risk of power outages or system failures, helping to keep public infrastructure running smoothly.

Special Environments: The S22-M-80 is also suitable for specialized environments like communication base stations, research institutions, and data centers, where uninterrupted and high-quality power is crucial. This transformer ensures that sensitive equipment operates without risk, providing the necessary power stability and security for these critical facilities.

The S22-M-80 is a cost-effective, energy-efficient transformer that offers high performance and reliability across a wide range of applications. Whether for industrial, commercial, or public sector use, it provides the power security needed to maintain smooth and efficient operations.
