630kVA Oil-Immersed Transformer
High Efficiency and Energy Saving: Utilizing new materials and optimized design, it complies with the latest energy efficiency standards, reducing energy consumption and operational costs.
Environmental Protection and Safety: High-quality insulating oil is used, providing excellent insulation and heat dissipation properties; additionally, it is equipped with an explosion-proof device to ensure safe operation.
Safety and Stability: It has good overload capacity and short-circuit resistance, ensuring long-term stable operation.
Low Noise: The structure of the core and windings is optimized, effectively reducing the noise level during operation.
Easy Installation: The size is moderate, and the weight is light, facilitating transportation and installation.
The S22-M-630 is an advanced oil-immersed transformer with a rated capacity of 630kVA, part of the S22 series that represents the next generation of high-efficiency, energy-saving distribution transformers. Designed to meet the latest industry energy efficiency standards, the S22-M-630 combines superior performance with reliability, offering a cost-effective solution for various applications across industrial, commercial, and public sectors.
Main Features:
High Efficiency and Energy Saving: The S22-M-630 utilizes state-of-the-art materials and a finely optimized design to ensure maximum energy efficiency. By minimizing no-load and load losses, it significantly reduces both energy consumption and operational costs. This design not only meets the latest energy efficiency standards but also provides a long-term solution that minimizes environmental impact while maximizing savings on electricity.
Environmental Protection and Safety: The transformer uses high-quality insulating oil, which not only provides exceptional insulation but also facilitates effective heat dissipation during its operation. This ensures that the transformer remains within safe temperature limits, reducing the risk of overheating and damage. Additionally, the S22-M-630 is equipped with an explosion-proof device to ensure safe and secure operation in challenging or hazardous conditions, providing peace of mind for users.
Safety and Stability: Designed for high performance and reliability, the S22-M-630 boasts excellent overload capacity and strong short-circuit resistance, ensuring stable operation even under difficult conditions. The transformer is built to withstand varying load demands and adverse environmental factors, making it a dependable option for critical infrastructure and facilities that require continuous, stable power supply.
Low Noise: The core and winding structure of the S22-M-630 has been carefully optimized to minimize noise during operation. This transformer is particularly suitable for environments where noise reduction is a priority, such as residential areas, hospitals, and offices, providing a quieter and more comfortable environment without compromising on performance.
Easy Installation: The S22-M-630 is designed for ease of transportation and installation, featuring a compact size and lightweight construction. This makes it an ideal choice for installations where space is limited, or where rapid deployment is required. The simplicity of installation further reduces the overall setup time and costs, making it a cost-efficient solution for both new installations and system upgrades.
Technical Parameters (Example):
Rated Capacity: 630kVA
Voltage Levels: Typically 10kV/0.4kV or customized configurations
Cooling Method: Oil-immersed self-cooling
Connection Group: Yyn0 or Dyn11
Insulation Class: Class B or higher
Protection Class: IP20 or higher
Application Scenarios:
The S22-M-630 is versatile and ideal for a wide range of applications across several fields:
Small and Medium Industrial Fields: Perfect for small to medium-sized factories, workshops, and production facilities that require a steady and reliable power supply. The transformer ensures the smooth operation of machinery, equipment, and manufacturing processes, helping to maintain efficiency and minimize downtime.
Commercial Fields: The S22-M-630 is an excellent choice for small and medium-sized commercial establishments such as shopping malls, office buildings, hotels, and other facilities. It provides dependable power for lighting, HVAC systems, elevators, and other essential services, ensuring smooth business operations and a comfortable environment for customers and employees alike.
Civil Fields: In residential areas, schools, hospitals, and other public buildings, the S22-M-630 ensures the provision of reliable power for daily activities, including lighting, heating, air conditioning, and medical equipment. It plays a crucial role in maintaining the comfort and safety of communities and supporting educational and healthcare operations.
Special Environments: The S22-M-630 is well-suited for locations with specific power quality demands, such as communication base stations, research institutions, and other critical facilities. These applications require transformers that provide clean and stable power without interruptions, and the S22-M-630 excels in meeting these needs by ensuring a constant and reliable power supply.
In summary, the S22-M-630 oil-immersed transformer offers a combination of energy efficiency, safety, and versatility that makes it ideal for a wide range of applications. Its advanced design, reliability, and ease of installation make it a cost-effective and long-lasting solution for industrial, commercial, and public facilities seeking high-quality, efficient power distribution.
