Single PhaseD11 25kVA
Energy-efficient rolled core structure;
Strong overload capacity and high reliability;
Maintenance-friendly
Single Phase D11/D13 160kVA 10 0.23 Oil-Immersed
Small Footprint and Minimal Investment: This pole-mounted transformer is designed to minimize infrastructure costs, making it suitable for rural grids, remote locations, and villages where power distribution is spread out.
Application Areas: Ideal for agricultural power supply, lighting, railway systems, and rural areas with decentralized power needs.
Design Advantages: Equipped with an energy-efficient rolled core design, the transformer offers robust overload resistance and reliable performance. Its simple design makes it maintenance-friendly and cost-effective over time.
le Mounted Distribution Tansformer
Rated Power (KVA) | High Voltage (V) | Low Voltage (V) | Loss (w) | Dimension(mm) | Weight(Kg) | ||||
No-load Loss(W) | Load Loss(W) | W | D | H | Oil Weight | Total Weigh | |||
5 | 34500 19920 13800 7957 13200 7620 12470 7200 or others | 19 36 50 80 105 135 190 210 350 | 75 120 195 290 360 500 650 850 1410 | 465 | 485 | 855 | 15 | 92 | |
10 | 500 | 525 | 885 | 22 | 150 | ||||
15 | 120-240 | 520 | 565 | 905 | 30 | 210 | |||
25 | 240-480 | 560 | 590 | 935 | 45 | 258 | |||
37.5 | 347 | 610 | 625 | 935 | 50 | 340 | |||
50 | 600 | 635 | 675 | 1035 | 62 | 395 | |||
75 | 745 | 840 | 1035 | 88 | 480 | ||||
100 | 770 | 965 | 1135 | 94 | 530 | ||||
167 | 795 | 890 | 1335 | 138 | 680 | ||||
