Pole Mounted Transformer
1. Compact Design and Low Investment: Specifically designed for pole-mounted installations, requiring minimal infrastructure investment, making it suitable for rural grids, remote areas, and dispersed villages.
2. Wide Application Range: Ideal for agricultural power supply, lighting systems, railway systems, and rural areas with dispersed power distribution.
3. Superior Design Features: Energy-efficient rolled core structure, strong overload capacity, high reliability, and maintenance-friendly design for extended lifespan.
Product Details
The Pole-mounted Transformer is a compact and cost-effective solution designed for pole-mounted installations, particularly in areas with limited infrastructure. It is ideal for applications in rural grids, remote areas, and dispersed villages, providing efficient and reliable power distribution with minimal investment.
Product Features
Compact Size and Minimal Investment: Designed for pole-mounted installations, requiring low infrastructure investment, suitable for rural grids, remote areas,and dispersed villages.
Applications: Ideal for agricultural power supply, lighting, railway systems, and rural areas with dispersed power distribution.
Design Features
Energy-efficient rolled core structure
Strong overload capacity and high reliability
Maintenance-friendly
Specifications
Rated Power(KVA) | High Voltage(V) | Low Voltage(V) | Loss (w) | Dimension(mm) | Weight(Kg) | ||||
No-load Loss(W) | Load Loss(W) | W | D | H | Oil Weight | Total Weight | |||
5 | 34500 19920 13800 7957 13200 7620 12470 7200 or others | 19 | 75 | 465 | 485 | 855 | 15 | 92 | |
10 | 36 | 120 | 500 | 525 | 885 | 22 | 150 | ||
15 | 120-240 | 50 | 195 | 520 | 565 | 905 | 30 | 210 | |
25 | 240-480 | 80 | 290 | 560 | 590 | 935 | 45 | 258 | |
37.5 | 347 | 105 | 360 | 610 | 625 | 935 | 50 | 340 | |
50 | 600 | 135 | 500 | 635 | 675 | 1035 | 62 | 395 | |
75 | 190 | 650 | 745 | 840 | 1035 | 88 | 480 | ||
100 | 210 | 850 | 770 | 965 | 1135 | 94 | 530 | ||
167 | 350 | 1410 | 795 | 890 | 1335 | 138 | 680 | ||
