Solar Inverter
1. Stable Output: Built-in control circuits and feedback mechanisms ensure stable voltage and frequency, even during fluctuations in the working process.
2. Reliable Protection: Includes overload, short circuit, and over-temperature protection to prevent abnormal working conditions, improving the inverter’s stability and reliability.
3. Intelligent Monitoring: Integrated intelligent monitoring allows real-time health diagnostics of the system, with data acquisition and transmission for timely maintenance.
4. Environmental Protection: Reduces environmental pollution by using solar power generation and improves safety by preventing AC output from returning to solar panels.
Product Details
The inverter is designed to stabilize voltage and frequency fluctuations during operation, ensuring consistent performance. It includes built-in protection mechanisms such as overload, short circuit, and over-temperature protection to safeguard against abnormal conditions. Additionally, the inverter features intelligent monitoring to continuously assess the health of the system, transmitting real-time operational data for maintenance and troubleshooting. By utilizing solar power generation, it contributes to environmental protection and enhanced safety, with features that prevent reverse current flow to the solar panels.
Product Features
Stabilized Performance: Ensures stable voltage and frequency through advanced control circuits and feedback systems.
Comprehensive Protection: Equipped with overload, short circuit, and over-temperature protection to prevent system failures.
Intelligent Monitoring: Continuous system health checks with data transmission for proactive maintenance.
Safety and Environmental Benefits: Solar-powered, reducing environmental pollution and ensuring safe operation with protection against reverse current.
Product Parameters
Protection Features: Overload protection, short circuit protection, over-temperature protection.
Monitoring: Built-in intelligent monitoring for system health diagnosis and feedback.
Power Source: Solar power generation.
Safety: Prevents the inverter’s AC output from flowing back into the solar panel system.
Environmental Impact: Eco-friendly and contributes to reducing pollution.
Maximum DC Input Power | 3-294KW | |||
Maximum DC Input Voltage | 1100V、1500V | |||
MPPT Voltage Range | 180-1000V、480-1080V | |||
Recommended MPP operating voltage | 650V、1080 | |||
Number of MPPTs | 2~14 | |||
Maximum number of MPPT input strings per circuit | 1、2 | |||
Rated Output Power | 3-196kW | |||
Maximum Output Power | 3.6-216kW | |||
Rated Grid Voltage | 400V-920V | |||
Grid voltage range | 310-480Vac | |||
Rated grid frequency | 50Hz/60Hz | |||
Grid frequency range | 45~55Hz/55~65Hz | |||
THD | ＜2% (rated power) | |||
Power factor | ＞0.99 (Rated power)/Adjustable range 0.8 overrun ~ 0.8 hysteresis | |||
DC component | ＜0.5%(Rated Power) | |||
System | ||||
Maximum efficiency | 98.00% | |||
European efficiency | 97.90% | 98% | 98.20% | 98.10% |
Humidity range | 0~100%，Non-condensing | |||
Cooling method | Intelligent speed control air-cooled | |||
Operating temperature range | -25~+60℃ | |||
Permissible altitude | 4000m | |||
Display | LED indication/LCD display (optional) | |||
Communication | RS485/GPRS/Wifi (optional) | |||
Protection class | IP66 | |||
